ION Meter IC7687.103
The triple-measurement controllers measuring and regulating electrochemical quantities using selective ion sensors (ISE), pH, redox and conductivity. The sensors allow the simultaneous display of up to three measurements on the display in addition to the temperature measurement which also operates in automatic compensation. The flexibility of use of the various types of sensor makes the instrument suitable for many applications and types of system.
-
DescriptionDocument Files
The triple-measurement controllers measuring and regulating electrochemical quantities using selective ion sensors (ISE), pH, redox and conductivity. The sensors allow the simultaneous display of up to three measurements on the display in addition to the temperature measurement which also operates in automatic compensation. The flexibility of use of the various types of sensor makes the instrument suitable for many applications and types of system.
Main features • Display: multi-line graph • Inputs: the three main inputs allow the selection of the following measures o Input A: conductivity/TDS/resistivity/indirect o Input B: ISE/pH/redox o Input C: ISE/pH/redox o Pt100 or Pt1000 (dedicated input) • 2 logical inputs for hold / alarm function • Manual and automatic temperature compensation • 2 set points for each input addressable on each of the 4 relays • Alarm • 2 analog outputs: 0-20 mA / 4-20 mA for PID) • RS485 and Modbus digital communication • Self-cleaning function • Self-calibration function (for ISE sensors, one or two points) • Degassing function (for ISE calibration) • Configuration of parameters on two levels using access codes chosen by the operator • Ambient temperature: 0/50 °C • Power supply: 85/264 V - 50/60 Hz • Container: ABS protection IP 66 • Dimensions: 256 x 230 x 89 mm • Registered ornamental model: 002564666-002 Related Products
